Single column electronic universal testing machine

This machine is mainly used to measure the mechanical properties and related physical parameters of various materials under tension, compression, bending, shear and other states. Equipped with different fixtures, it can also be used for peeling, puncture and other tests. It has the characteristics of compact structure, simple operation and convenient maintenance. It is an ideal testing and testing equipment for colleges and universities, scientific research institutes, quality inspection departments and related production units.

Send email to us

Product Detail

Product Tags

Product function and purpose

本机主要用于测定各种材料在拉伸、压缩、弯曲、剪切等状态下的力学性能及有关物理参数。配备不同夹具亦可做撕剥离、穿刺等试验。

具有结构紧凑，操作简单，维护方便等特点，是大专院校、科研院所、质检部门及有关生产单位理想的试验检测设备.

Product specifications

Testing machine type			EH- 5103D	EH- 5503D	EH- 5104D
Maximum load (N)			1000 5000 10000
Load accuracy			Grade 0.5 better than indicating soil
accuracy	Measurement	Load	Indication value taxi within 0.5%
		Morphed	Soil within 0.5% of the indicated value
		Displacem ent	Indication value taxi within 0.5%
Beam displacement speed adjustment range			0.01 ~ 500 mm/min

Stretch space (mm			600
Overall dimensions of the host (L x W x H)			480×450×1350 mm
Motor power			400W:220V±10%	400W:220V±10%	750W:220V±10%
Machine weight (Kg)			65
Note: The company reserves the right to upgrade the instrument without prior notice, please ask for details when consulting .

Testing machine standard

1. It meets the requirements of GB / t2611-2007 general technical requirements for testing machines, GB / t16826-2008 electrohydraulic servo universal testing machines and JB / t9379-2002 technical conditions for tension compression fatigue testing machines;

2. Meet GB / t3075-2008 metal axial fatigue test method, GB / t228-2010 metallic materials tensile test method at room temperature, etc;

3. It is applicable to GB, JIS, ASTM, DIN and other standards.
